ELODE Specification

Model No
Sludge Input Width (typical)
Input Voltage (typical)
Power Consumption (typical)
Wet Sludge Feed-in wt (typical)
Input Sludge Cake DS (typical)
Output Cake DS (typical)
Typical Belt Speed
Typical Washer Water Use
Compressed Air Use (max)
Sludge Conductivity Range
Base Unit Dimension LxWxH
Base Unit Weight (est)
Power Supply and Controller
Controller Weight (est)
EODS-500
10 in
3 Phase, 460 VAC
30 kWh
240-390 lb/hr
10-30% from Mechanical Presses
30-50%, max 60%+ observed
3 to 6 ft/min
gal/min
1.5 gal/min @100 psi
2,000-10,000 uS/cm
128 x 76 x 100 in
3.5 ton
40 x 40 x 72 in
1 ton
EODS-1000
24 in
70 kWh
630-1,000 lb/hr

gal/min
128 x 100 x 100 in
4.5 ton
48 x 48 x 76 in
1.5 ton
EODS-2000
64 in
120 kWh
1,100-1,700 lb/hr

10 gal/min
128 x 140 x 100 in
6 ton
48 x 80 x 76 in
2 ton
EODS-3000
98 in
180 kWh
2,600-4,200 lb/hr

13 gal/min
128 x 180 x 100 in
8 ton
48 x 112 x 76 in
2.5 ton

Note:  Specification are subject to change depending on many factors.  There are thousands of types of sludge.  We may modify the machine to be more suitable for custom application of our customers.
